Wiring Device-Kellems L630R
Wiring Device-Kellems Select Spec™ Twist-Lock® L630R 1-Phase Grounding Standard Single Screw Mount Locking Receptacle, 250 VAC, 30 A, 2 Poles, 3 Wires, Black
- Manufacturer Name: Hubbell
- MPN: L630R
- Brand Name: Wiring Device-Kellems
- UPC: 783585835969
- FEPN: L630R HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Select Spec™ Twist-Lock® Locking Receptacle, 1-Phase Grounding Standard Single Screw Mount, 250 VAC, 30 A, 2 Pole, 3 Wires, L6-30R/WD1/WD5 NEMA Rating, Commercial/Industrial Grade, -40 to 85 deg C, Screw Terminal, Thermoplastic, Black, 1.703 in W x 1.312 in D
| Dimensions | : | 1.703 in W x 1.312 in D |
| Grade | : | Commercial/Industrial |
| Material | : | Thermoplastic |
| NEMA Rating | : | L6-30R/WD1/WD5 |
| Temperature Rating | : | -40 to 85 deg C |
| Terminal Type | : | Screw |
| Type | : | 1-Phase Grounding Standard Single Screw Mount |
| Voltage Rating | : | 250 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | Black |
- Flush mount
- Indoor dry unless protected by additional means
- Screw mount
- 10 AWG wire
Instruction/Installation Manual
