Wiring Device-Kellems HBL2825
Wiring Device-Kellems Insulgrip® Twist-Lock® HBL2825 3-Phase Standard Screw Mount Flanged Inlet, 277/480 VAC, 30 A, 4 Poles, 5 Wires, White
- Manufacturer Name: Hubbell
- MPN: HBL2825
- Brand Name: Wiring Device-Kellems
- UPC: 783585039718
- FEPN: HBL2825 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Insulgrip® Twist-Lock® Flanged Inlet, 3-Phase Standard Screw Mount, 277/480 VAC, 30 A, 4 Pole, 5 Wires, L22-30P NEMA Rating, -40 to 75 deg C, Screw Terminal, Nylon, White, 3.06 x 3.06 x 2.27 in
| Dimensions | : | 3.06 x 3.06 x 2.27 in |
| Material | : | Nylon |
| NEMA Rating | : | L22-30P |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 3-Phase Standard Screw Mount |
| Voltage Rating | : | 277/480 VAC |
| Amperage Rating | : | 30 A |
| Number of Poles | : | 4 |
| Number of Wires | : | 5 |
| Color | : | White |
- Withstands 2000 VAC minimum dielectric voltage
- Certified for current interrupting at full rated current
- 30 A 10 AWG terminal accommodation
- HB or better per UL 94 or CSA 22.2 NO 0.6 flammability
- Terminals identified in accordance with UL 498 (X, Y, Z, white, green)
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 0.75
- #10-32 brass terminal screw material
- Brass blade
- Clear polycarbonate terminal retainer material
- 0.08 in steel-nickel plated terminal clamp
- Steel, zinc plated multi drive body holding screw material
- Natural white nylon body contact carrier material
- Natural white nylon flanged casing material
- Nickel-plated brass round head mounting screw material
- 3-phase
- Impact-resistant thermoplastic construction
- Back wired terminations for ease of installation
- Mounting screws included
