Wiring Device-Kellems 20308001A
Wiring Device-Kellems 20308001A Non-Mounted Standard Pulling Swivel, 2250 lb Load, 7/8 in Trade, 3/8 in W Eye
- Manufacturer Name: Hubbell
- MPN: 20308001A
- Brand Name: Wiring Device-Kellems
- UPC: 783585326351
- FEPN: 20308001A HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems Pulling Swivel, Non-Mounted Standard, 2250 lb Load, 7/8 in Trade, 31/32 in Eye Length, 3/8 in Eye Width, 3-3/8 in Overall Length, Stainless Steel
| Eye Length | : | 31/32 in |
| Material | : | Stainless Steel |
| Overall Length | : | 3-3/8 in |
| Type | : | Non-Mounted Standard |
| Load Capacity | : | 2250 lb |
| Trade Size | : | 7/8 in |
| Eye Width | : | 3/8 in |
- Swivels are essential to the efficiency and safety of any high tension application
- They are particularly important where continuous pulls develop higher and higher torque levels
- Torque is intensified by the pull-resistance of the cable itself and the resistance of the high tension controlling equipment regulating line sag
- Ball bearing swivels release torque and prevent it from reaching dangerous levels that can damage the cable and obstruct the lines
