Series G molded case circuit breakers are designed for circuit protection needs across the globe. A complete line of user friendly accessories and high performance interruption ratings meet a host of different application, industry and regional requirements. Current ratings range from 15 to 2500 A with voltages up to 690 VAC. Thermal magnetic and electronic trip units are available as well as residual ground fault and 30 mA earth leakage protection options.

EATON, EGB3032FFG, 3-Pole Molded Case Circuit Breaker, Type EGB, Series: G Series, 600Y/347 VAC, 32 A, 50/60 Hz Frequency, 18/25 kA Interrupt, EG Frame, Fixed Thermal/Fixed Magnetic Trip, 3 Pole, 3 ph, Toggle Handle Actuator, Standard Line/Load Connection, NEMA AB1-1993 Enclosure, -20 to 70 deg C, 2.99 x 3 x 5.5 in Dimensions, Glass Polyester

• Compact design frees up panel space
• Common field-fit internal accessories make installation and custom configuration easy
• Advanced trip unit functionality offers a wide range of adjustment for maximum flexibility
• Patented contact design features high speed blow-open action, resulting in superior performance
• Mounting hardware and lugs are included for convenience, eliminating the need for separate parts orders
• Circuit breakers significantly outperform the calculations listed in the institute of electrical and electronic engineers (IEEE) standard 1584, guide for performing arc flash hazard calculations
• Meets the requirements of UL, CSA, IEC, CCC and CE, providing a truly global design and worldwide acceptance
• 25 kA at 240 VAC, 18 kA at 415/480 VAC interrupt rating

• Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_EGB3032FFG_Specification_Sheet.pdf
• Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_EGE3050FFEA1_User_Manual.pdf
• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/LGX425032W_Installation_Manual_01.pdf
• VIDEO LINK https://www.youtube.com/watch?v=8d24HtN6GZw
