Wiring Device-Kellems CS320I
Send Print
  1. pin-int

Wiring Device-Kellems CS320I

Wiring Device-Kellems CS320I 3-Way Standard AC Toggle Switch, 120 to 277 VAC, 20 A, 5540 W Power Rating, 2-Position Contact

  • Manufacturer Name: Hubbell
  • MPN: CS320I
  • Brand Name: Wiring Device-Kellems
  • UPC: 783585902159
  • FEPN: CS320I HW
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Wiring Device-Kellems AC Toggle Switch, 3-Way Standard, 120 to 277 VAC, 20 A, 5540 W Power, 2-Position Contact Configuration, 1 Pole, Toggle Actuator, Threaded Mounting, Side Wire Terminal, 50000 cycles Operating Cycles, Nylon, Ivory, Environmental Conditions: -40 to 75 deg C, 4.18 x 1.49 x 1.83 in

Actuator       :      Toggle
Color       :      Ivory
Dimensions       :      4.18 x 1.49 x 1.83 in
Environmental Conditions       :      -40 to 75 deg C
Material       :      Nylon
Mounting       :      Threaded
Number of Poles       :      1
Operating Cycles       :      50000 cycles
Terminal Type       :      Side Wire
Type       :      3-Way Standard
Voltage Rating       :      120 to 277 VAC
Amperage Rating       :      20 A
Power Rating       :      5540 W
Contact Configuration       :      2-Position
  • Integral ground terminals
  • Silver cadmium oxide contacts
  • 1-piece rivetless spring contact arm and terminal plate
  • Ground terminal anchor hole
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_5b890cc7c9271265135ca7e90a7d7efaf79b7165a6d7edfa7d73de9e6e753197.pdf
  • pdfLine Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_7de30f17f40cbbc0cffa5d87b97cab9f97b9300698368d97fa0fdd463de3c467.pdf
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device_Kellems_HBL1201I_Catalog.pdf
