Wiring Device-Kellems HBL26520
Wiring Device-Kellems HBL26520 Grounding Heavy Duty Multi-Phase Non-NEMA Single Standard Screw Mount Locking Receptacle, 600 VAC, 60 A, 4 Poles, 5 Wires, Blue
- Manufacturer Name: Hubbell
- MPN: HBL26520
- Brand Name: Wiring Device-Kellems
- UPC: 783585017518
- FEPN: HBL26520 HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL26520, Locking Receptacle, Grounding Heavy Duty Multi-Phase Non-NEMA Single Standard Screw Mount, 600 VAC, 60 A, 4 Pole, 5 Wires, Industrial Grade, NEMA 4X/12/IP20 Enclosure, -40 to 75 deg C, Screw Terminal, Composite/Thermoplastic/Aluminum, Blue, 3.5 x 4.62 x 4.96 in Dimensions
| Dimensions | : | 3.5 x 4.62 x 4.96 in |
| Enclosure | : | NEMA 4X/12/IP20 |
| Grade | : | Industrial |
| Material | : | Composite/Thermoplastic/Aluminum |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | Grounding Heavy Duty Multi-Phase Non-NEMA Single Standard Screw Mount |
| Voltage Rating | : | 600 VAC |
| Amperage Rating | : | 60 A |
| Number of Poles | : | 4 |
| Number of Wires | : | 5 |
| Color | : | Blue |
- Cast aluminum top cover
- 0.032 in bronze ground contact
- Black polyester body contact carrier
- Withstands 2000 VAC minimum dielectric voltage
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150 Percent of rated current at a power factor of 75 Percent temperature rise
- Auto ejects improperly made connection
- Spring loaded safety shutter automatically ejects the plug eliminating contact teasing
- 6 AWG wire
- Box terminals in conjunction with stainless steel screws provide maximum termination strength and dependability
- Metallic weather protective spring loaded cover provides protection from moisture and dust
Instruction/Installation Manual
