EATON offers BR 1 in circuit breakers with a thermal magnetic trip curve that avoids nuisance tripping on mild overloads while reacting almost instantaneously to severe short circuit conditions.
EATON Circuit Breaker, Type BR, 120/240 VAC, 80 A, 10 kA Interrupt, Common Trip, 2 Pole, 1 ph, Handle Actuator, 8 to 1/0 AWG Wire, Plug-On Mount, 40 deg C, 3 in L x 2 in W x 3 in H
| Actuator Type | : | Handle |
| Dimensions | : | 3 in L x 2 in W x 3 in H |
| Mounting Type | : | Plug-On |
| Phase | : | 1 |
| Temperature Rating | : | 40 deg C |
| Type | : | Type BR |
| Wire Size | : | 8 to 1/0 AWG |
| Voltage Rating | : | 120/240 VAC |
| Amperage Rating | : | 80 A |
| Interrupt Rating | : | 10 kA |
| Number of Poles | : | 2 |
| Trip Type | : | Common |
- All BR circuit breakers have rejection tab feature
- Units feature a quick make, quick break switch mechanism combined with inverse time element tripping operation and trip free handle design
- Standard interrupting capacity
Line Drawing
