Wiring Device-Kellems HBL24CM23
Send Print
  1. pin-int

Wiring Device-Kellems HBL24CM23

Wiring Device-Kellems Twist-Lock® Insulgrip® HBL24CM23 3-Phase Heavy Duty Isolated Grounding Standard Sized Cord Mount Female Connector, 250 Delta VAC, 20 A, 3 Poles, 4 Wires, Yellow

  • Manufacturer Name: Hubbell
  • MPN: HBL24CM23
  • Brand Name: Wiring Device-Kellems
  • UPC: 783585038506
  • FEPN: HBL24CM23 HW
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Wiring Device-Kellems Twist-Lock® Insulgrip® Female Connector, 3-Phase Heavy Duty Isolated Grounding Standard Sized Cord Mount, 250 Delta VAC, 20 A, 3 hp, 3 Pole, 4 Wires, L15-20R/WD1/WD5 NEMA Rating, Industrial/Marine Grade, IP20 Enclosure, 0.35 to 1.15 in Diameter Cord, -40 to 75 deg C, Pressure Screw Terminal, Composite, Yellow, 2.33 x 2.33 x 3.86 in

Cord Diameter       :      0.35 to 1.15 in
Dimensions       :      2.33 x 2.33 x 3.86 in
Enclosure       :      IP20
Grade       :      Industrial/Marine
Horsepower       :      3 hp
Material       :      Composite
NEMA Rating       :      L15-20R/WD1/WD5
Temperature Rating       :      -40 to 75 deg C
Terminal Type       :      Pressure Screw
Type       :      3-Phase Heavy Duty Isolated Grounding Standard Sized Cord Mount
Voltage Rating       :      250 Delta VAC
Amperage Rating       :      20 A
Number of Poles       :      3
Number of Wires       :      4
Color       :      Yellow
  • Ribbed nylon housing provides a secure grip and impact and chemical resistance
  • Superior cord grip design for flat cable protects terminations from excess strain
  • Integral dust shield protects wiring chamber from dust or contaminants
  • Corrosion resistant
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b12c51917fa207551b883fffeecd0fd5c47ddbc0b42e3198c8b5f1c5ebabcff9.pdf
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_fb09dc4b76e86f96c0b309550b652d1cbfaf484069a4381f80c529f3dcafb09d.pdf
  • pdfLine Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ff841c7f1971de33399fa82b6b756f8fac14fa1b3d34cfc1807aefebe4d8cdb6.pdf
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device_Kellems_HBL21CM414B_Catalog.pdf
  • linkVIDEO LINK https://youtu.be/1DnPJu3QNw0
