Emergi-Lite® EL-2SQR
Send Print
  1. pin-int

Emergi-Lite® EL-2SQR

Emergi-Lite® EL-2SQR EL ESCORT II Self-Powered Battery Unit, 5.4 W Incandescent Lamp, 120/277 VAC, 6 VDC, 2 Heads, Thermoplastic

  • Manufacturer Name: Thomas & Betts
  • MPN: EL-2SQR
  • Brand Name: Emergi-Lite®
  • UPC: 782683229090
  • FEPN: EL2SQR EML
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Emergi-Lite® Battery Unit, Self-Powered, Series: EL ESCORT II, 120/277 VAC, 6 VDC, 0.04 A, Incandescent Lamp, 5.4 W Lamp, Wedge Base, 2 Heads, Ceiling Mount, 5-1/8 in H x 16-1/4 in W x 4-3/8 in D, Thermoplastic, Off-White

Amperage Rating       :      0.04 A
Base Type       :      Wedge
Color       :      Off-White
Dimensions       :      5-1/8 in H x 16-1/4 in W x 4-3/8 in D
Mounting Type       :      Ceiling
Series       :      EL ESCORT II
Type       :      Self-Powered
Lamp Wattage       :      5.4 W
Lamp Type       :      Incandescent
Voltage Rating       :      120/277 VAC, 6 VDC
Number of Heads       :      2
Material       :      Thermoplastic
  • Two fully adjustable glare free 6 V, 5.4 W DC T5 wedge base lamps for emergency mode egress light
  • Injection molded UV stabilized thermoplastic housing and back plate, 5VA flame rated
  • Sealed, maintenance free lead calcium batteries, designed to power 11 W remote load or extended unit run time
  • LED indicator light and push button test switch
  • 11 watts remote capacity, low voltage battery disconnect
  • Innovative, snap together design allows for fast installation, wall or ceiling mounting, universal knockout pattern on the back plate allows for junction box mounting
  • Damp location listing is standard in all models
  • 23 W at 1-1/2 hr
  • pdfSpecification Sheet https://assets.unilogcorp.com/2/ITEM/DOC/Emergi_Lite_EL_2SQ_Data_Sheet.pdf
