Pass & Seymour® TR62I
Pass & Seymour® TR62I 3-Phase Duplex Extra Heavy Duty Tamper-Resistant Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Ivory
- Manufacturer Name: Legrand
- MPN: TR62I
- Brand Name: Pass & Seymour®
- UPC: 785007145229
- FEPN: TR62-I PS
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Pass & Seymour® Straight Blade Receptacle, 3-Phase Duplex Extra Heavy Duty Tamper-Resistant, 125 VAC, 15 A, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Commercial/Specification Grade, -40 to 60 deg C, Back/Side Wire Terminal, Nylon, Ivory, 1.625 in L x 0.9 in W x 3.281 in H Dimensions
| Dimensions | : | 1.625 in L x 0.9 in W x 3.281 in H |
| Grade | : | Commercial/Specification |
| Material | : | Nylon |
| NEMA Rating | : | NEMA 5-15R |
| Temperature Rating | : | -40 to 60 deg C |
| Terminal Type | : | Back/Side Wire |
| Type | : | 3-Phase Duplex Extra Heavy Duty Tamper-Resistant |
| Voltage Rating | : | 125 VAC |
| Amperage Rating | : | 15 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | Ivory |
- Thermoplastic dual mechanism shutter system to help prevent insertion of foreign objects
- Auto-ground clip assures positive ground
- Easily accessed break-off line contact connecting tab for fast and easy split circuit wiring
- 1-piece brass, triple wipe power contacts for lasting retention
- Strap tabs wrap-around and lock down on face to prevent strap from separating from face and back body
- Extra heavy duty galvanized steel, 1-piece mounting strap with integral ground
- Exclusive patented feature, circuit label on face allows permanent circuit identification
- Exclusive patented feature, external screw pressure plate back wire clamp-on ground terminal for faster, easier installation
- Withstands 2000 VAC minimum dielectric voltage
- Surge protective, corrosion-resistant, led indication
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here
- Temperature Rise, Maximum 30 deg C temperature rise at full-rated current after 50 cycles of overload at 150 Percent of rated current with direct current
- Operating Temperature, Maximum continuous +60 deg C, minimum -40 deg C without impact
