Pass & Seymour® Straight Blade Plug, Dusttight, 125 VAC, 15 A, 1/2 hp, 60 Hz, 2 Poles, 3 Wires, NEMA 5-15P, Industrial Grade, IP20 Enclosure, 0.335 to 0.64 in Cord Dia, -40 to 75 deg C, Threaded Terminal, Rubber, Yellow, 1.6 in Dia x 2.44 in H x 1.53 in W
| Cord Diameter | : | 0.335 to 0.64 in |
| Dimensions | : | 1.6 in Dia x 2.44 in H x 1.53 in W |
| Enclosure | : | IP20 |
| Frequency Rating | : | 60 Hz |
| Grade | : | Industrial |
| Horsepower | : | 1/2 hp |
| Material | : | Rubber |
| NEMA Rating | : | NEMA 5-15P |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Threaded |
| Type | : | Dusttight |
| Voltage Rating | : | 125 VAC |
| Amperage Rating | : | 15 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | Yellow |
- 1600 VAC minimum dielectric withstand voltage
- Certified for current interrupting at full rated current
- 30 deg C maximum, 50 cyclest 150% rated current temperature rise
- 14 AWG wire size
- Thermoplastic elastomeric body, polycarbonate terminal chamber, nylon compression nut, thermoplastic elastomeric compression grommet and dust cover
- Floating blades allow self alignment with contacts for a firm, even electrical connection
- Quick-drive assembly screws allow for fast installation, saving time and money
- Self-centering cord clamps provide superior strain relief
- Rubber body construction stands up to impacts, oils, chemicals, heat, and weather
- Nickel-plated blades and contacts for long-lasting, superior corrosion resistance
