Wiring Device-Kellems HBL2313BK
Wiring Device-Kellems HBL2313BK Heavy Duty Female Grounding Insulated Standard Cord Mount Locking Connector, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
- Manufacturer Name: Hubbell
- MPN: HBL2313BK
- Brand Name: Wiring Device-Kellems
- UPC: 783585172194
- FEPN: HBL2313BK HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL2313BK, Locking Connector, Heavy Duty Female Grounding Insulated Standard Cord Mount, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, L5-20R NEMA Rating, Industrial Grade, NEMA 4X/12/IP20 Enclosure, 0.36 to 0.93 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Black, 2.26 x 2.26 x 3.86 in Dimensions
| Cord Diameter | : | 0.36 to 0.93 in |
| Dimensions | : | 2.26 x 2.26 x 3.86 in |
| Enclosure | : | NEMA 4X/12/IP20 |
| Grade | : | Industrial |
| Horsepower | : | 1 hp |
| Material | : | Nylon |
| NEMA Rating | : | L5-20R |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | Heavy Duty Female Grounding Insulated Standard Cord Mount |
| Voltage Rating | : | 125 VAC |
| Amperage Rating | : | 20 A |
| Number of Poles | : | 2 |
| Number of Wires | : | 3 |
| Color | : | Black |
- All black ribbed nylon housing provides a secure grip and impact and chemical resistance
- Superior cord grip design protects terminations from excess strain
- Clear, funnel shaped wire entry for ease of termination
- Integral dust shield protects wiring chamber from dust or contaminants
- Black nylon contact nose and cord clamp, clear polycarbonate terminal retainer
- 0.08 in steel nickel plated terminal clamp, #10-32 brass (white finish on neutral screw when used) multi-drive terminal screw, green finish multi-drive ground screw, steel, zinc plated multi-drive cord clamp screw arterial and body holding screw
- Natural white nylon body contact carrier
- Brass contact spring and spring binding plate
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150 Percent of rated current at a power factor of 75 Percent temperature rise
- Withstands 2000 VAC minimum dielectric voltage
- Cord mounted
- Indoor dry unless protected by additional mean environmental conditions
- 14 to 12 AWG conductor
