EATON EHD3010L
EATON EHD3010L C Series Type EHD Molded Case Circuit Breaker, 480 VAC/250 VDC, 10 A, 14 kAIC at 480 VAC/18 kAIC at 240 VAC Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip
- Manufacturer Name: Eaton
- MPN: EHD3010L
- Brand Name: EATON
- UPC: 786679317020
- FEPN: EHD3010L EC
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
EATON series C molded case circuit breakers are used in panelboard, switchboard, motor control center and busway applications for dependable branch circuit protection. They have proven user acceptance for over 20 years and meet or exceed North American standards. Available for systems up to 600 VAC/250 VDC with current ratings up to 2500 A.
EATON Molded Case Circuit Breaker, Type EHD, Series: C Series, 480 VAC/250 VDC, 10 A, 50/60 Hz, 14 kAIC at 480 VAC/18 kAIC at 240 VAC Interrupt, F Frame, Fixed Thermal/Fixed Magnetic Trip, 3 Pole, Handle Actuator, Line/Load, 40 deg C, 3.38 x 4.13 x 6 in
| Actuator Type | : | Handle |
| Connection Type | : | Line/Load |
| Dimensions | : | 3.38 x 4.13 x 6 in |
| Frame | : | F |
| Frequency Rating | : | 50/60 Hz |
| Series | : | C Series |
| Temperature Rating | : | 40 deg C |
| Type | : | Type EHD |
| Voltage Rating | : | 480 VAC/250 VDC |
| Amperage Rating | : | 10 A |
| Interrupt Rating | : | 14 kAIC at 480 VAC/18 kAIC at 240 VAC |
| Number of Poles | : | 3 |
| Trip Type | : | Fixed Thermal/Fixed Magnetic |
- Patented contact design features high speed "blow-open" action, resulting in superior performance
- Suitable for reverse feed applications
- 18 kA at 240 VAC, 14 kA at 480 VAC interrupt rating
