Panduit® S6-10R-E
Panduit® Pan-Lug™ S6-10R-E S-R Series Loose Piece Non-Insulated Tubular Ring Terminal, 6 AWG Conductor, 1.2 in L, Beveled/Seamless Barrel, Copper, Metallic
- Manufacturer Name: Panduit
- MPN: S6-10R-E
- Brand Name: Panduit®
- UPC: 074983598700
- FEPN: S6-10R-E PC
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Panduit® Pan-Lug™ Ring Terminal, Loose Piece Non-Insulated Tubular, Series: S-R Series, Stranded Conductor, 6 AWG Conductor, 0.19 in Stud, 1.2 in Length, Beveled/Seamless Barrel, 0.22 in ID x 0.31 in OD x 0.48 in L Barrel, Ring Straight Tongue, 0.45 in W x 0.09 in THK Tongue, 35 kVAC, 1/2 in L Wire Strip, 1/2 in Mounting Hole, 90 deg C, Copper, Tin Plated, Metallic
| Barrel Size | : | 0.22 in ID x 0.31 in OD x 0.48 in L |
| Conductor Type | : | Stranded |
| Finish | : | Tin Plated |
| Series | : | S-R Series |
| Specifications | : | 1/2 in L Wire Strip, 1/2 in Mounting Hole |
| Stud Size | : | 0.19 in |
| Temperature Rating | : | 90 deg C |
| Tongue Size | : | 0.45 in W x 0.09 in THK |
| Tongue Type | : | Ring Straight |
| Type | : | Loose Piece Non-Insulated Tubular |
| Voltage Rating | : | 35 kVAC |
| Conductor Size | : | 6 AWG |
| Length | : | 1.2 in |
| Barrel Type | : | Beveled/Seamless |
| Material | : | Copper |
| Color | : | Metallic |
- Seamless tubular barrel provides a consistent high performance quality crimp
- Round double thick tongue for reliable power applications
- Barrel of terminal internally beveled to provide quick and easy wire insertion
- Inspection window allows visual inspection of proper wire insertion
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Technical Bulletin
VIDEO LINK
