Wiring Device-Kellems HBL5252GY
Send Print
  1. pin-int

Wiring Device-Kellems HBL5252GY

Wiring Device-Kellems HBL® HBL5252GY 1-Phase Compact Duplex Extra Heavy Duty Self-Grounding Standard Traditional Screw Mount Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Gray

  • Manufacturer Name: Hubbell
  • MPN: HBL5252GY
  • Brand Name: Wiring Device-Kellems
  • UPC: 783585434889
  • FEPN: HBL5252GY HW
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Wiring Device-Kellems HBL® Straight Blade Receptacle, 1-Phase Compact Duplex Extra Heavy Duty Self-Grounding Standard Traditional Screw Mount, 125 VAC, 15 A, 1/2 hp, 2 Pole, 3 Wires, 5-15R NEMA Rating, Commercial/Industrial Grade, -40 to 75 deg C, Side Wired Terminal, Thermoplastic/Composite, Gray, 3.28 x 1.33 x 1.05 in

Dimensions       :      3.28 x 1.33 x 1.05 in
Grade       :      Commercial/Industrial
Horsepower       :      1/2 hp
Material       :      Thermoplastic/Composite
NEMA Rating       :      5-15R
Temperature Rating       :      -40 to 75 deg C
Terminal Type       :      Side Wired
Type       :      1-Phase Compact Duplex Extra Heavy Duty Self-Grounding Standard Traditional Screw Mount
Voltage Rating       :      125 VAC
Amperage Rating       :      15 A
Number of Poles       :      2
Number of Wires       :      3
Color       :      Gray
  • One piece brass ground strap
  • Exclusive bypass contact design for greater contact force and reduced heat buildup
  • Barbed assembly arms reduce possibility of face/base separation
  • Finder groove face
  • Triple wipe contacts
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_361ecbaa8da63b51d65d26de456306fc8eed2920a67babb3d1aad339cc09575b.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_42bddc49d18d8f4dc632829431c02672885ef4b318a6b517fdc768ab8bc8b6c1.pdf
  • pdfLine Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_8210adf425ba09b12b6dfcec13bbdbdb850d81c86ec51dc3fcbd74e936f1f30f.pdf
  • pdfFull Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Wiring_Device_Kellems_HBL5252GY_Full_Engineering_Drawing.pdf
