Pass & Seymour® PS15AC4W
Pass & Seymour® PS15AC4W 4-Way Extra Heavy Duty Toggle Switch, 120/277 VAC, 15 A, 4 W Power Rating
- Manufacturer Name: Legrand
- MPN: PS15AC4W
- Brand Name: Pass & Seymour®
- UPC: 785007196757
- FEPN: PS15AC4-W PS
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Pass & Seymour® Toggle Switch, 4-Way Extra Heavy Duty, 120/277 VAC, 15 A, 4 W Power, Toggle Actuator, Wall Mounting, Back/Side Wire Terminal, Thermoplastic, White, 3.3 in H x 1.32 in W x 1.073 in D Dimensions
| Actuator | : | Toggle |
| Color | : | White |
| Dimensions | : | 3.3 in H x 1.32 in W x 1.073 in D |
| Material | : | Thermoplastic |
| Mounting | : | Wall |
| Terminal Type | : | Back/Side Wire |
| Type | : | 4-Way Extra Heavy Duty |
| Voltage Rating | : | 120/277 VAC |
| Amperage Rating | : | 15 A |
| Power Rating | : | 4 W |
- External screw pressure plate back and side wired, accepts 14 to 10 AWG copper or copper clad conductors
- Heavy gauge 1-piece copper alloy contact arm virtually eliminates contact bounce
- Cam controls fast make and positive break to minimize arcing
- Heavy duty bumper pads for quiet operation
- High strength thermoplastic polycarbonate toggle
- Back body made of glass reinforced nylon
- Locking support provides resistance to face and back body separation
- Oversized silver alloy contacts for long life and better heat dissipation
- Grounding terminal is standard
- Shallow design for ease of installation
- Strap nickel plated steel with integral ground
- Auto-ground clip assures positive ground
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here
