Wiring Device-Kellems HBL2511S
Wiring Device-Kellems HBL2511S 3-Phase Grounding Male Standard Cord Mount Locking Plug, 120/208 VAC, 20 A, 4 Poles, 5 Wires, Black/White
- Manufacturer Name: Hubbell
- MPN: HBL2511S
- Brand Name: Wiring Device-Kellems
- UPC: 783585235028
- FEPN: HBL2511S HW
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Wiring Device-Kellems, HBL2511S, Locking Plug, 3-Phase Grounding Male Standard Cord Mount, 120/208 VAC, 20 A, 2 hp, 4 Pole, 5 Wires, L21-20P NEMA Rating, Industrial Grade, IP20 Enclosure, 0.35 to 1.15 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Black/White, 2.33 x 2.33 x 4.21 in Dimensions
| Cord Diameter | : | 0.35 to 1.15 in |
| Dimensions | : | 2.33 x 2.33 x 4.21 in |
| Enclosure | : | IP20 |
| Grade | : | Industrial |
| Horsepower | : | 2 hp |
| Material | : | Nylon |
| NEMA Rating | : | L21-20P |
| Temperature Rating | : | -40 to 75 deg C |
| Terminal Type | : | Screw |
| Type | : | 3-Phase Grounding Male Standard Cord Mount |
| Voltage Rating | : | 120/208 VAC |
| Amperage Rating | : | 20 A |
| Number of Poles | : | 4 |
| Number of Wires | : | 5 |
| Color | : | Black/White |
- Ribbed nylon housing provides a secure grip and impact and chemical resistance
- Superior cord grip design protects terminations from excess strain
- Integral dust shield protects wiring chamber from dust or contaminants
