EATON XTCE007B10B
EATON XTCE007B10B B-Frame Full Voltage Non-Reversing IEC Contactor, 220 VAC at 50 Hz, 240 VAC at 60 HZ V Coil, 7 A, 1NO Contact, 3 Poles
- Manufacturer Name: Eaton
- MPN: XTCE007B10B
- Brand Name: EATON
- FEPN: XTCE007B10B EC
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Small size. Big impact. The XT IEC contactors are powerful, efficient and versatile, and can be combined with our full range of electronic overload relays and bimetal relays. These DC devices stand out for their reduced power consumption, which makes them more energy efficient and also reduces the size of the power supply units. XT IEC contactors are suitable for global use and cover the entire output range, from mini contactor relays (up to 7 A) all the way to vacuum contactors (up to 3180 A).
EATON IEC Contactor, B-Frame Full Voltage Non-Reversing, Series: XTCE, 220 VAC at 50 Hz, 240 VAC at 60 HZ Coil, 7 A Maximum Load Current, 1/4 hp at 115 VAC 1 ph, 3/4 hp at 200 VAC 1 ph, 1 hp at 230 VAC 1 ph, 1-1/2 hp at 200 VAC 3 ph, 2 hp at 230 VAC 3 ph, 3 hp at 460 VAC 3 ph, 5 hp at 575 VAC 3 ph Coil Power Rating, 3 Pole, 50/60 Hz, 1NO, 45 mm, Screw Terminal, DIN Rail/Panel Mount
| Coil Power Rating | : | 1/4 hp at 115 VAC 1 ph, 3/4 hp at 200 VAC 1 ph, 1 hp at 230 VAC 1 ph, 1-1/2 hp at 200 VAC 3 ph, 2 hp at 230 VAC 3 ph, 3 hp at 460 VAC 3 ph, 5 hp at 575 VAC 3 ph |
| Frequency Rating | : | 50/60 Hz |
| Mounting Type | : | DIN Rail/Panel |
| Series | : | XTCE |
| Size | : | 45 mm |
| Terminal Type | : | Screw |
| Type | : | B-Frame Full Voltage Non-Reversing |
| Coil Voltage | : | 220 VAC at 50 Hz, 240 VAC at 60 HZ |
| Maximum Load Current | : | 7 A |
| Contact Configuration | : | 1NO |
| Number of Poles | : | 3 |
- 2.2 kW at 220/230 VAC 3 ph, 3 kW at 380/400 VAC 3 ph, 4 kW at 415 VAC 3 ph 50/60 Hz coil power rating
Specification Sheet
