Wiring Device-Kellems B2075
Send Print
  1. pin-int

Wiring Device-Kellems B2075

Wiring Device-Kellems Kellems Wire Management PolyTuff® II B2075 Non-Metallic Standard Liquidtight Tubing, 3/4 in Trade, 0.83 in ID x 1.04 in OD, 100 ft L, PVC

  • Manufacturer Name: Hubbell
  • MPN: B2075
  • Brand Name: Wiring Device-Kellems
  • UPC: 783585333229
  • FEPN: B2075 HW
  • Min Order Qty: 100
  • Quantity Interval: 100
  • Inventory Availability loading loading

Wiring Device-Kellems Kellems Wire Management PolyTuff® II Liquidtight Tubing, Non-Metallic Standard, 3/4 in Trade, 0.83 in ID, 1.04 in OD, 100 ft Length, 0.21 in Thickness, 3 in Bend Radius, 300 VAC, Extra Flexible Flexibility, -18 to 60 deg C, PVC, Black, Ribbed

Bend Radius       :      3 in
Color       :      Black
Finish       :      Ribbed
Flexibility       :      Extra Flexible
Temperature Rating       :      -18 to 60 deg C
Thickness       :      0.21 in
Type       :      Non-Metallic Standard
Voltage Rating       :      300 VAC
Trade Size       :      3/4 in
Inside Diameter       :      0.83 in
Outside Diameter       :      1.04 in
Length       :      100 ft
Material       :      PVC
  • Cap nut connection
  • Chemical-resistant
  • PVC core with corrugated walls bonded to PVC jacket
  • Handles twists, turns, bends, switchbacks and straightaway's with ease
  • All non-metallic construction ends fatigue and separation problems
  • Can be cut with a knife or PVC cutters
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_f8fa32bbea8292ee60268665e3d2722ab92ce8f864fd27d6a54b07c2f6f53919.pdf
