Blackburn® AMTS25064
Blackburn® AMTS25064 AMT Same Sided Insulated Multi-Port Connector, 6 AWG to 250 kcmil Conductor Copper Conductor, 5/16 in Hex Screw Installation, Aluminum
- Manufacturer Name: ABB
- MPN: AMTS25064
- Brand Name: Blackburn®
- UPC: 783786669691
- FEPN: AMTS25064 TB
- Min Order Qty: 1
- Quantity Interval: 10
-
Inventory Availability
-
Retail Price:
The high quality and built-in flexibility of the Blackburn® AMT connectors reduce the cost of field installations on splices, taps and terminations. Theyre easy and quick to install and provide superior insulation that lasts the life of the connection.
Blackburn®, AMTS25064, Same Sided Insulated Multi-Port Connector, Series: AMT, Copper Conductor, 6 AWG to 250 kcmil Conductor, 5/16 in Hex Screw Installation, 600 V AC, Ultraviolet Resistance, Specifications: 5/16 in Hex Screw, Black Color, 90 deg C, Aluminum, 4.06 in L x 2.13 in W x 2.13 in H Dimensions
| Dimensions | : | 4.06 in L x 2.13 in W x 2.13 in H |
| Resistance | : | Ultraviolet |
| Series | : | AMT |
| Specifications | : | 5/16 in Hex Screw, Black Color |
| Temperature Rating | : | 90 deg C |
| Type | : | 4-Port Same Sided Insulated |
| Voltage Rating | : | 600 V AC |
| Conductor Size | : | 6 AWG to 250 kcmil |
| Conductor Type | : | Copper |
| Installation Type | : | 5/16 in Hex Screw |
| Material | : | Aluminum |
- PVC insulation eliminates insulation failures and reduces outage costs
- Removable port and screw plugs
- Compact design provides space efficiencies
- All cable entry are equipped with an anti-oxidation compound
- Superior connections with lower installation costs
- Ultraviolet resistant
Specification Sheet
