Arlington L423
Send Print
  1. pin-int

Arlington L423

Arlington L423 Single Screw Cable Connector With 0.94 in Dia Round End Stop, 1 in Trade, 1 in Knockout, 1.255 to 1.375 in Cable Openings, Die Cast Zinc

  • Manufacturer Name: Arlington
  • MPN: L423
  • Brand Name: Arlington
  • UPC: 018997342300
  • FEPN: L423 AR
  • Min Order Qty: 1
  • Quantity Interval: 10
  • Inventory Availability loading loading

Arlington Cable Connector, Single Screw, 1 in Trade, 1 in Knockout, Cable Openings: 1.255 to 1.375 in, Flex/AC/MC/MCI Cable, Threaded x Squeeze Connection, Die Cast Zinc, Silver, 1.86 in L x 1.86 in W x 1.74 in H Dimensions

Cable Type       :      Flex/AC/MC/MCI
Color       :      Silver
Connection Type       :      Threaded x Squeeze
Dimensions       :      1.86 in L x 1.86 in W x 1.74 in H
Type       :      Single Screw
Trade Size       :      1 in
Knockout Size       :      1 in
Cable Openings       :      1.255 to 1.375 in
Material       :      Die Cast Zinc
  • Concretetight when taped
  • pdfWarranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Arlington_314S_Warranty.pdf
  • pdfLine Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Arlington_L420_Line_Drawing.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Arlington_L423_Specification_Sheet.pdf
