The 3M™ aluminum connectors ci series are for splicing applications on aluminum or copper cable conductors. The ci series aluminum connectors are specially designed for use with 3M™ pre-molded power cable splice bodies QS, QS-II and QS-III . Each connector is electro-tin plated to resist electrolytic corrosion and have a solid center stop.
3M™, 7100052593, Connector, Series: CI Series, Aluminum/Stranded Copper Conductor, 350 kcmil Conductor, 3.7 in Length, Compression Connector, 35 kVAC, 1-1/8 in OD Dimensions
| Connector Type | : | Compression |
| Dimensions | : | 1-1/8 in OD |
| Series | : | CI Series |
| Voltage Rating | : | 35 kVAC |
| Conductor Size | : | 350 kcmil |
| Conductor Type | : | Aluminum/Stranded Copper |
| Length | : | 3.7 in |
| Material | : | Aluminum |
- Built-in solid center oil stop allows for correct positioning
- Rated for 15 kV and 25 kV molded rubber splices
- Made of aluminum for good conductivity and tin plating for corrosion-resistance
- Standard barrel ensures a secure fit and offers reliable performance
Specification Sheet
