Lithonia Lighting® SBL2 LP835
Lithonia Lighting® SBL2 LP835 SBL2 Rectangular Square Basket Indoor Wraparound Fixture, (4) Lamps, 120 to 277 V AC, Gloss White Housing
- Manufacturer Name: Acuity Brands
- MPN: SBL2 LP835
- Brand Name: Lithonia Lighting®
- UPC: 190887819458
- FEPN: SBL2 LP835 LI
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
The SBL LED wraparound provides a digital lighting platform to deliver general ambient lighting for surface mount applications. The LED system delivers long life and excellent color to ensure a quality, low-maintenance lighting installation. Ideal for closets, storage rooms, hallways and offices.
Lithonia Lighting®, SBL2 LP835, Indoor Wraparound Fixture, Rectangular Square Basket, Series: SBL2, 120 to 277 V AC, 23 W Lamp, T8 Lamp Base, 4 Lamps, Clear Shade, LED Dimming Driver Ballast, Acrylic Diffuser Lens, Surface Mounting, Steel Housing Material, Gloss White Housing Finish, 2 ft L x 8-5/8 in W x 2-5/8 in H Dimensions
| Ballast Type | : | LED Dimming Driver |
| Dimensions | : | 2 ft L x 8-5/8 in W x 2-5/8 in H |
| Housing Material | : | Steel |
| Lamp Base Type | : | T8 |
| Lamp Wattage | : | 23 W |
| Lens Type | : | Acrylic Diffuser |
| Mounting Type | : | Surface |
| Series | : | SBL2 |
| Shade Type | : | Clear |
| Type | : | Rectangular Square Basket |
| Number of Lamps | : | 4 |
| Lamp Type | : | LED |
| Voltage Rating | : | 120 to 277 V AC |
| Housing Finish | : | Gloss White |
- Linear side prisms control brightness, pyramidal bottom prisms minimize lamp image
- Continuous side flanges on fixture body provide light trap and continuous diffuser support to prevent accidental opening and simplify maintenance
- Full depth, white enamel end plates
- Die-formed from code gauge cold-rolled steel, channel cover snaps into place without the use of tools
- Full end cap factory installed to reduce job site labor, diffuser is extruded clear acrylic
- Five-stage iron phosphate pretreatment ensures superior paint adhesion and rust resistance, finished with high-gloss, baked white enamel
- Thermally protected, resetting, class P, HPF ballast is standard, energy saving and electronic ballasts are sound rated A
- Luminaire is suitable for damp locations. AWM, TFN or THHN wire used throughout, rated for required temperatures
- The translucent white diffuser reduces glare and pixilation without impacting performance
- Long-life LEDs, coupled with high-efficiency drivers, provide superior quantity and quality of illumination for extended service life
- 90% LED lumen maintenance at 50,000 hr (L90/50,000)
