Arlington DBHB1C
Arlington InBox™ DBHB1C DB Series 1-Piece Low Profile Recessed Electrical Box, Plastic, 22 cu-in Capacity, 1 Gang, 1 Outlet, 4.934 in L x 7.186 in W x 5.159 in D
- Manufacturer Name: Arlington
- MPN: DBHB1C
- Brand Name: Arlington
- UPC: 018997776280
- FEPN: DBHB1C AR
- Min Order Qty: 1
- Quantity Interval: 1
-
Inventory Availability
-
Retail Price:
Recessed electrical box with weatherproof in use extra duty cover for existing siding construction. Non-metallic cover and base. accepts most 1-gang wiring devices and uses standard indoor wall plates or a GFCI cover plate. Box and white cover are textured/paintable UV rated plastic for long outdoor life.
Arlington InBox™ Electrical Box, 1-Piece Low Profile Recessed, Series: DB Series, 1 Outlet, 1 Gang, NEMA 3R Enclosure, Ceiling Mounting, Horizontal Mounting, 22 cu-in Capacity, Plastic, Painted/Textured, Clear/White, 4.934 in L x 7.186 in W x 5.159 in D Dimensions
| Color | : | Clear/White |
| Enclosure Type | : | NEMA 3R |
| Finish | : | Painted/Textured |
| Mounting Orientation | : | Horizontal |
| Mounting Type | : | Ceiling |
| Series | : | DB Series |
| Type | : | 1-Piece Low Profile Recessed |
| Material | : | Plastic |
| Capacity | : | 22 cu-in |
| Number of Gangs | : | 1 |
| Number of Outlets | : | 1 |
| Dimensions | : | 4.934 in L x 7.186 in W x 5.159 in D |
- InBox™ 1-piece assembly replaces the installation of an electrical box, siding block and bubble cover assembly
- Built-in anchor tabs seat InBox™ sleeve into mortar for super secure installation
- Installs in the wall, so less of It shows outside
- Installed, disposable, mud cover extends all the way over the flange, providing maximum protection during construction
- Cover is removable for easier device installation
- No gaskets required
- UV rated plastic for long outdoor life
