Arlington FBS405
Send Print
  1. pin-int

Arlington FBS405

Arlington FBS405 Fan/Fixture Mounting Box With Knockout, Steel, 6 cu-in Capacity, 2 Knockouts, 4.25 in L x 4.25 in W x 0.61 in H

  • Manufacturer Name: Arlington
  • MPN: FBS405
  • Brand Name: Arlington
  • UPC: 018997761859
  • FEPN: FBS405 AR
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Arlington Fan/Fixture Mounting Box, 2 Knockouts, 1/2 in Knockout, Knockout Cable Entry, 4-1/4 in Diameter, Round Shape, Threaded Mounting, 6 cu-in Capacity, Steel, Plated, Silver, 4.25 in L x 4.25 in W x 0.61 in H Dimensions

Cable Entry Size       :      Knockout
Color       :      Silver
Diameter       :      4-1/4 in
Finish       :      Plated
Knockout Size       :      1/2 in
Mounting Type       :      Threaded
Shape       :      Round
Material       :      Steel
Capacity       :      6 cu-in
Number of Knockouts       :      2
Dimensions       :      4.25 in L x 4.25 in W x 0.61 in H
  • No loose parts to misplace totally self-contained
  • Center screw is shipped-in place
  • Protective plastic tips on the installation screws for added safety
  • Combination hex/Phillips® head screws for easy installation with power screwdrivers
  • Fan fixture installation screws are parked ready for easy fan fixture bracket installation
  • Supports fan fixture up to 70 lb
  • UL rated for a 70 lb fan or 200 lb fixture and CSA rated for a 50 lb fan or fixture
  • Mounts directly to a joist for a secure installation
  • pdfWarranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Arlington_314S_Warranty.pdf
  • pdfLine Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Arlington_FBS405_Line_Drawing.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Arlington_FBS405_Specification_Sheet.pdf
