NSI Split Bolt Connector, Series: N Series, Solid/Stranded Copper Conductor, 1/0 AWG to 250 kcmil Conductor, 1.102 x 2.106 in Bolt, 600 VAC, Specifications: 1 Pole, 2 Conductor, 0.58 in Split, 1.4 in Hex Nut, 650 in-lb Torque, 90 deg C, Copper, 2.106 in L x 1.102 in W Dimensions
| Dimensions | : | 2.106 in L x 1.102 in W |
| Series | : | N Series |
| Specifications | : | 1 Pole, 2 Conductor, 0.58 in Split, 1.4 in Hex Nut, 650 in-lb Torque |
| Temperature Rating | : | 90 deg C |
| Voltage Rating | : | 600 VAC |
| Conductor Size | : | 1/0 AWG to 250 kcmil |
| Conductor Type | : | Solid/Stranded Copper |
| Bolt Size | : | 1.102 x 2.106 in |
| Material | : | Copper |
- Copper split bolt connectors are high strength solderless service connectors made of high copper alloy for copper and copper weld wires
- Split bolt type for two maximum wire sizes
- Class A and B wire type
- 7 x 5 AWG stranded for maximum conductor copper weld
- 10 AWG solid conductor range min tap with one max main
- 0.325 to 0.575 in Dia wire
- 1/0 AWG to 250 kcmil stranded conductor range for equal run and tap
