NSI Dual Rated Lug, Series: T Series, 6 AWG to 250 kcmil Conductor, 5/16 in Stud, 1 Bolt Holes, 1.13 in W x 0.22 in THK Tongue, 600 VAC, Specifications: 1 Pole, 1 Conductor, 5/16 in Wrench, 330 in-lb Torque, 90 deg C, Aluminum, Electro-Tin Plated, 2 in L x 0.88 in W x 1.02 in H Dimensions
| Dimensions | : | 2 in L x 0.88 in W x 1.02 in H |
| Finish | : | Electro-Tin Plated |
| Series | : | T Series |
| Specifications | : | 1 Pole, 1 Conductor, 5/16 in Wrench, 330 in-lb Torque |
| Temperature Rating | : | 90 deg C |
| Tongue Size | : | 1.13 in W x 0.22 in THK |
| Voltage Rating | : | 600 VAC |
| Conductor Size | : | 6 AWG to 250 kcmil |
| Stud Size | : | 5/16 in |
| Number of Bolt Holes | : | 1 |
| Material | : | Aluminum |
- Versatile and reusable set screw connectors made of 6061T-6 aluminum alloy
- Electro tin plated for low contact resistance
- 0.47 in hole center to tang end size
