Homac® SG-102
Send Print
  1. pin-int

Homac® SG-102

Blackburn® SG-102 Common Die Straight Service Entrance Splice, 1/0 AWG End A, 2 AWG End B Aluminum/Copper/Compact/Compressed/Stranded Conductor, Die Code: TU, 52, BG, 243, 5/8, 2 in L, Aluminum

  • Manufacturer Name: ABB
  • MPN: SG-102
  • Brand Name: Homac®
  • UPC: 783786751631
  • FEPN: SG 102 TB
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Blackburn® Service Entrance Splice, Straight, Series: Common Die, Aluminum/Copper/Compact/Compressed/Stranded Conductor, 1/0 AWG End A, 2 AWG End B Conductor, Die Code: TU, 52, BG, 243, 5/8, 2 in Length, Compression Connector, Specifications: 2-Conductors, Aluminum, Tin Plated

Connector Type       :      Compression
Finish       :      Tin Plated
Series       :      Common Die
Specifications       :      2-Conductors
Type       :      Straight
Conductor Size       :      1/0 AWG End A, 2 AWG End B
Conductor Type       :      Aluminum/Copper/Compact/Compressed/Stranded
Die Code       :      TU, 52, BG, 243, 5/8
Length       :      2 in
Material       :      Aluminum
  • Oxide inhibitor
  • 1/0 AWG stranded, 1/0 AWG compact, 1/0 AWG compressed, 1/0 AWG aluminum/copper, 2 AWG stranded, 2 AWG compact, 2 AWG compressed, 2 AWG aluminum/copper
  • pdfSDS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_54efd96734631a89642fd283019687a71b0674c3cb6c396739ae98be9f49449e.pdf
  • pdfCatalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Thomas_Betts_AC2R4_Catalog.pdf
