Homac® Compression Lug Connector, 2-Hole, Copper Conductor, 300 kcmil Conductor, Die Code: 66, 17, 781, 1/2 in Stud, Straight Tongue, 3 in L x 1-1/4 in W x 5/32 in THK Tongue, 5-3/4 in Overall Length, 2 in L Barrel, 1-3/4 in Hole Spacing, 9/16 in Dia Mounting Hole, Copper
| Barrel Size | : | 2 in L |
| Mounting Hole Size | : | 9/16 in Dia |
| Overall Length | : | 5-3/4 in |
| Specifications | : | 1-3/4 in Hole Spacing |
| Tongue Size | : | 3 in L x 1-1/4 in W x 5/32 in THK |
| Tongue Type | : | Straight |
| Type | : | 2-Hole |
| Conductor Size | : | 300 kcmil |
| Conductor Type | : | Copper |
| Die Code | : | 66, 17, 781 |
| Stud Size | : | 1/2 in |
| Material | : | Copper |
- TiN coated to resist corrosion
- Produced from seamless electrolytic copper tubing which provides high conductivity and minimizes voltage drop
- Marked with a catalog number, conductor sizes and dies references
- Two hole NEMA pad
