Federal Signal MSS-120

Federal Signal MicroStat® MSS-120 Sound Module, 120 VAC, 0.04 A, 83 to 85 dB, Plug-In Mount, ARRA Compliant|BAA Compliant|CSA Certified|cUL Listed|FM Approved|UL Listed

  • Manufacturer Name: Federal Signal
  • MPN: MSS-120
  • Brand Name: Federal Signal
  • UPC: 782979206996
  • FEPN: MSS-120 FS
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

Adding sound to the MicroStat® is simple with the plug-in sound module. The sound module produces 83 to 85 dBA at 10 ft. This compact piezo device replaces the lamp in the top position of any MicroStat®. A slotted opaque lens protects the sound module circuit and permits the sound to be heard at maximum levels. Adding the sound module to the MicroStat® changes the type rating from 4X to type 1. Sound modules are available in 24VDC and 120VAC operating voltages.

Federal Signal MicroStat® Sound Module, 120 VAC, 0.04 A, 83 to 85 dB Decibel, NEMA 1 NEMA Rating, Specifications Met: ARRA Compliant|BAA Compliant|CSA Certified|cUL Listed|FM Approved|UL Listed, Plug-In Mounting, 2.2 in W x 2.2 in D x 2 in H Dimensions

Dimensions       :      2.2 in W x 2.2 in D x 2 in H
NEMA Rating       :      NEMA 1
Voltage Rating       :      120 VAC
Amperage Rating       :      0.04 A
Decibel Rating       :      83 to 85 dB
Mounting Type       :      Plug-In
Specifications Met       :      ARRA Compliant|BAA Compliant|CSA Certified|cUL Listed|FM Approved|UL Listed
