Lithonia Lighting® REBL ALO16 UVOLT SWW3 80CRI DWH M2
Send Print
  1. pin-int

Lithonia Lighting® REBL ALO16 UVOLT SWW3 80CRI DWH M2

Lithonia Lighting® REBL ALO16 UVOLT SWW3 80CRI DWH M2 Round High Bay

  • Manufacturer Name: Acuity Brands
  • MPN: REBL ALO16 UVOLT SWW3 80CRI DWH M2
  • Brand Name: Lithonia Lighting®
  • UPC: 197590119370
  • FEPN: REBL ALO16 UVOLT SWW3 80CRI DWH M2 LI
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

The REBL LED High Bay by Lithonia Lighting features patent pending micro-prism optics that deliver uniform and comfortable illumination across the entire space. Packaged in a sleek, yet rugged diecast housing, the REBL's unique design redefines the round high bay by combining aesthetics, optical control, and UGR performance without wasting energy. REBL is Performance Simplified.

Lithonia Lighting®, REBL ALO16 UVOLT SWW3 80CRI DWH M2, High Bay, Round, Series: REBL, 120 to 347 V AC, 150/170/200 W Fixture, 3500/4000/5000 K Color Temperature, 80 CRI, Polycarbonate Lens, 24000/27000/30000 Lumens, IP66 Enclosure, Pendant Mounting, Die Cast Aluminum Housing Material, White Housing Finish

Color Rendering Index (CRI)       :      80
Color Temperature       :      3500/4000/5000 K
Enclosure Type       :      IP66
Housing Material       :      Die Cast Aluminum
Lens Type       :      Polycarbonate
Lumens       :      24000/27000/30000 Lumens
Mounting Type       :      Pendant
Series       :      REBL
Type       :      Round
Fixture Wattage       :      150/170/200 W
Voltage Rating       :      120 to 347 V AC
Housing Finish       :      White
  • The REBL LED High Bay by Lithonia Lighting features patent pending micro-prism optics that deliver uniform and comfortable illumination across the entire space
  • Packaged in a sleek, yet rugged diecast housing, the REBL's unique design redefines the round high bay by combining aesthetics, optical control, and UGR performance without wasting energy
  • TECHNOLOGY - 24,000/27,000/30,000 Adjustable Lumen Output (ALO) and 3500K/4000K/5000K Switchable White (SWW) features allow for this high bay to offer 9 potential configurations within one fixture, using two switches
  • ENERGY SAVINGS - High-efficiency LEDs provide up to 187 LPW
  • DIMMING - 0-10 V driver for dimming down to 10 percent
  • VOLTAGE - MVOLT for 120-347 V
  • HOURS OF LIFE - Greater than 70 percent LED lumen maintenance at 100,000 hr (L70 greater than 100,000)
  • Optional cast loop or surface mount bracket available separately
  • BATTERY - Field Installable 40 Wemergency battery pack
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lithonia_Lighting_REBL_ALO13_UVOLT_SWW3_80CRI_DBL_M2_Instruction_Installation_Manual.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lithonia_Lighting_REBL_ALO13_UVOLT_SWW3_80CRI_DBL_M2_Specification_Sheet.pdf
  • videoVIDEO LINK https://www.youtube.com/watch?v=b2aNRZKBKTg
