Lithonia Lighting® TWX LED wall pack family’s ground-up design delivers superior illumination in a traditional form while providing the low initial cost that customers demand. TWX LED wall packs feature premium borosilicate glass lenses that work in conjunction with the high-efficiency light engine to provide superior illumination while minimizing wasted up-light. The new slim design creates a less obtrusive appearance on the building while still fully covering the unsightly stains leftover from typical metal halide glass wall packs. The TWX1 LED is energy efficient saving up to 83% in energy costs when replacing a metal halide luminaire. The Adjustable Light Output (ALO) feature allows the contractor to set the light output during installation, to a level perfectly suited for the job site. The TWX1 LED ALO luminaires can replace anything from a CFL to 100W metal halide luminaire.

Lithonia Lighting® Contractor Select™ Wallpack, Rectangular Adjustable Light Output, Series: TWX1 Series, 120 to 277 V AC, 22 W Fixture, LED Lamp, 100000 hr Average Life, 4000 K Color, Electronic/0 to 10 V Dimmable Driver Ballast, Borosilicate Glass Lens, 600 to 2950 Lumens, IP65, Surface Mount, Die Cast Aluminum Housing, Textured Dark Bronze Housing, 7-1/2 in W x 5 in D x 12 in H

• TWX LED wall packs feature premium borosilicate glass lenses that work in conjunction with the high-efficiency light engine to provide superior illumination while minimizing wasted up-light
• The new slim design creates a less obtrusive appearance on the building while still fully covering the unsightly stains leftover from typical metal halide glass wall packs
• The TWX1 LED is energy efficient saving up to 83% in energy costs when replacing a metal halide luminaire
• The Adjustable Light Output (ALO) feature allows the contractor to set the light output during installation, to a level perfectly suited for the job site
• TECHNOLOGY - Adjustable light output maximizes flexibility in the field
• Dial in the lumens you need through a rotary switch located inside of the luminaire
• PHOTOCELL - Hardwired on/off capability only
• VOLTAGE - MVOLT for 120-277V (50/60Hz)
• HOURS OF LIFE - Light engine consists of high-efficacy LEDs mounted to housing to maximize heat dissipation and promote long-life (up to L81/100,000 hr at 25C)
• FINISH - Exterior painted parts are protected by a zinc-infused Super Durable TGIC thermoset powder coat finish providing superior resistance to corrosion and weathering withstanding extreme climate changes without cracking or peeling
• BATTERY BACKUP - No emergency battery back-up available in this version

• Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lithonia_Lighting_TWX1_LED_ALO_50K_MVOLT_DDBTXD_Specification_Sheet.pdf
• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lithonia_Lighting_TWX3_LED_ALO_50K_MVOLT_DDBTXD_Installation_Manual.pdf
• VIDEO LINK https://youtu.be/li9lDCzcl24
