Juno® WF4 DREG B ALO19 SWW5 90CRI MW M6

Juno® WF4 DREG B ALO19 SWW5 90CRI MW M6 WF4 DREG Adjustable Regressed Switchable Downlight, Incandescent Lamp, 14.5 W Fixture, 120 V, Die-Cast Aluminum Housing

  • Manufacturer Name: Acuity Brands
  • MPN: WF4 DREG B ALO19 SWW5 90CRI MW M6
  • Brand Name: Juno®
  • UPC: 197589041361
  • FEPN: WF4 DREG B ALO19 SWW5 90CRI MW M6 LI
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

The 4in Canless Wafer Downlight has an innovative, slim design that installs quickly and easily into as little as 3in of plenum space allowing for it to fit into ceiling spaces where most traditional recessed housings do not. Wafers install directly into dry wall eliminating the need for recessed housings. Once installed, our Wafer provides an all-in-one design featuring switchable white color temperature and adjustable lumen output technology. This technology gives the ultimate in flexibility, providing you the equivalent of 15 static products in one.

Juno®, WF4 DREG B ALO19 SWW5 90CRI MW M6, Regressed Switchable Downlight, Adjustable, Series: WF4 DREG, 120 V, 14.5 W Fixture, Incandescent Lamp, 65 W Lamp, 50000 hrs Average Life, 2700/3000/3500/4000/5000 K Color Temperature, 90 CRI, TRIAC Ballast, Polycarbonate Lens, 700/900/1100 Lumens, Die-Cast Aluminum Housing Material

Average Life       :      50000 hrs
Ballast Type       :      TRIAC
Color Rendering Index (CRI)       :      90
Color Temperature       :      2700/3000/3500/4000/5000 K
Lamp Wattage       :      65 W
Lens Type       :      Polycarbonate
Lumens       :      700/900/1100 Lumens
Series       :      WF4 DREG
Type       :      Adjustable
Lamp Type       :      Incandescent
Fixture Wattage       :      14.5 W
Voltage Rating       :      120 V
Housing Material       :      Die-Cast Aluminum
  • The 4in Canless Wafer Downlight has an innovative, slim design that installs quickly and easily into as little as 3in of plenum space allowing for it to fit into ceiling spaces where most traditional recessed housings do not
  • Once installed, our Wafer provides an all-in-one design featuring switchable white color temperature and adjustable lumen output technology
  • This technology gives the ultimate in flexibility, providing you the equivalent of 15 static products in one
  • DESIGN - Wafer Downlights feature a canless design, meaning no housing is required for installation
  • Wafers are also slim in design, so they fit when ceiling space is limited
  • ENERGY SAVINGS - Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life
  • DIMMABLE - Dimming to 10 percent
  • EASY INSTALLATION - Installs directly below the ceiling for easy retrofit, remodel or new construction, no housing required
  • HOURS OF LIFE - Long life energy efficient LED
  • FEATURE BENEFIT - The Wafer is designed with two switches located directly on the product to change color temperature from 2700K (warm white) up to 5000K (daylight), or change lumens from 700, 900, or 1100
  • Emergency battery currently not available
  • pdfInstruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Juno_WF4_DREG_B_ALO19_SWW5_90CRI_MW_M6_Installation_Manual.pdf
  • pdfSpecification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Juno_WF4_DREG_B_ALO19_SWW5_90CRI_MW_M6_Specification_Sheet.pdf
  • videoVIDEO LINK https://www.youtube.com/watch?v=AX2nakIlWOw
