The CNY LED ALO Canopy Luminaire from Lithonia Lighting is where versatility meets innovation! With an incredible 54 customizable options packed into a single luminaire, you have the power to tailor your lighting experience right on the spot. Adjust color temperature, lumen output, photocell settings, and even activate the integrated motion sensor. It's your lighting, your way! The CNY LED ALO’s 10" x 10" footprint, matching that of typical HID luminaires, goes beyond aesthetics. It expertly conceals any unsightly imperfections, ensuring a seamless, hassle-free installation that eliminates the need for extra patching or repairs. Transform your outdoor space with the CNY LED ALO and enjoy the perfect combination of visually comfortable illumination, energy efficiency, and complete customization – all bundled in a sleek and durable package.

Lithonia Lighting®, CNY LED ALO SWW2 UVOLT PE PIR DDB M2, Canopy Lighting, Square, Series: CNY, 120 to 347 V, 34, 52, 75 W Fixture, 139/147/143/133/144/137/123/136/125 Lumens/W Light Output, 100000 hrs Average Life, 3000/4000/5000 K Color Temperature, 80 CRI, 0 to 10 V Continuous Dimmable Ballast, Frosted Lens, 5000/7500/10000 Lumens, Surface Mounting, Die-Cast Aluminum Housing Material, Dark Bronze Housing Finish, 3 in H x 10 in W x 10 in D Dimensions

• The CNY LED ALO Canopy Luminaire from Lithonia Lighting is where versatility meets innovation With an incredible 54 customizable options packed into a single luminaire, you have the power to tailor your lighting experience right on the spot
• It's your lighting, your way The CNY LED ALOs 10 in x 10 in footprint, matching that of typical HID luminaires, goes beyond aesthetics
• It expertly conceals any unsightly imperfections, ensuring a seamless, hassle-free installation that eliminates the need for extra patching or repairs
• Transform your outdoor space with the CNY LED ALO and enjoy the perfect combination of visually comfortable illumination, energy efficiency, and complete customization all bundled in a sleek and durable package
• HOURS OF LIFE - High-efficiency LEDs maintains over 70% of light output at 100,000 hr (L70 greater than 100,000 hr)
• INSTALLATION - Quick-mount plate that makes mounting to a recessed junction box or conduit entry point both quick and trouble free and can be separated for surface mounting and reattached via a hinge for support while wiring

• Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lithonia_Lighting_CNY_LED_ALO_SWW2_UVOLT_PE_PIR_WH_M2_Installation_Manual.pdf
• Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Lithonia_Lighting_CNY_LED_ALO_SWW2_UVOLT_PE_PIR_WH_M2_Specification_Sheet.pdf
• VIDEO LINK https://www.youtube.com/watch?v=EMoqlWJeyPc&feature=youtu.be
