Juno® WF8 SWW5 90CRI MW M6

Juno® WF8 SWW5 90CRI MW M6 WF8 Downlight, LED Lamp, 21 W Fixture, 120 V, Aluminum Housing

  • Manufacturer Name: Acuity Brands
  • MPN: WF8 SWW5 90CRI MW M6
  • Brand Name: Juno®
  • UPC: 194994243915
  • FEPN: WF8SWW590CRIMWM6
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Inventory Availability loading loading

The Wafer LED Downlights with Switchable White technology provides high-quality light output and efficiency and features a switch for easy color temperature adjustment, while eliminating the need for recessed housings.

Juno®, WF8 SWW5 90CRI MW M6, Downlight, Series: WF8, 120 V, 21 W Fixture, LED Lamp, 19 W Lamp, 1 Lamps, 8 in Round Recessed Trim, 50000 hr Average Life, 2700/3000/3500/4000/5000 K Color Temperature, 90 CRI, Dimmable Ballast, 1700 Lumens, Recessed Mounting, Aluminum Housing Material, 1-3/16 in H x 8 in W x 8 in D Dimensions

Average Life       :      50000 hr
Ballast Type       :      Dimmable
Color Rendering Index (CRI)       :      90
Color Temperature       :      2700/3000/3500/4000/5000 K
Dimensions       :      1-3/16 in H x 8 in W x 8 in D
Lamp Wattage       :      19 W
Lumens       :      1700 Lumens
Mounting Type       :      Recessed
Number of Lamps       :      1
Recessed Trim Type       :      8 in Round
Series       :      WF8
Lamp Type       :      LED
Fixture Wattage       :      21 W
Voltage Rating       :      120 V
Housing Material       :      Aluminum
  • The Wafer LED Downlights with Switchable White technology provides high-quality light output and efficiency and features a switch for easy color temperature adjustment, while eliminating the need for recessed housings
  • DESIGN - This innovative wafer-slim design allows easy installation for new construction or remodel from below the ceiling without the requirement of a housing for insulation, it easily replaces up to 65 Wincandescent downlights
  • ENERGY SAVINGS - Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life
  • DIMMING - Dimming down to 10 percent
  • VOLTAGE - Dedicated to 120 V
  • HOURS OF LIFE - Greater than 70 percent LED lumen maintenance at 50,000 hr (L70 greater than 50,000)
  • INSTALLATION - Easy installation with low profile integrated LED downlight along with an easy to handle compact size, installs into wood joists with a new construction pan
  • BATTERY - Field-installable LED emergency driver sold separately
